Unlaminated Films

Unlaminated Films
  Gafchromic™ films are designed to provide fast and highly accurate measurements for Gamma and X-ray dosimetry applications. When used with specifically designed Film QA Pro™ software, Gafchromic™ film provides the most complete and accurate dosimetric measurement. Instant high- resolution images ...Read more



  • Description
  • Specifications



Gafchromic™ films are designed to provide fast and highly accurate measurements for Gamma and X-ray dosimetry applications.

When used with specifically designed Film QA Pro™ software, Gafchromic™ film provides the most complete and accurate dosimetric measurement. Instant high- resolution images provide the high data integrity needed to increase confidence and peace of mind for both the physicist and the patient alike.

Unlaminated films do not have the top layer of the film which allows for the active chemistry to be exposed. Unlaminated films are designed primarily for low energy detection which includes photons, electrons, and UV rays. Unlaminated films are used for research applications.

  • Dose Range: Up to 1000 GY





Product Code Product Format Dose/Energy Range
849952 EBT3-810 unlaminated 8”x10”, 25 sheets per box 0.2 GY – 10 GY
100 KeV into the MV
941814 EBT-XD unlaminated 8”x10”, 25 sheets per box 0.4 GY – 40 GY
100 KeV into the MV
972412 LD-V1 1212 unlaminated 10”x12”, 10 sheets per box 2 cGY – 20 GY
~20 KeV – 200 KeV
